Godox WEC 2-Person Wireless Microphone System for Cameras and Mobile Devices (2.4 GHz)

Description

Godox WEC 2-Person Wireless Microphone System for Cameras and Mobile Devices (2.4 GHz)

Key Features

• For Content Creation, Vlogging
• For 2-Person Shoots with Camera or Phone
• 2 x Transmitters with Built-In Mics
• Dual-Channel Receiver
• 3.5mm TRS Audio Output, USB-C Charging
• 3.5mm TRS to TRRS Audio Adapter Cable
• 200m Transmission Distance
• Intelligent Noise Reduction, ±6 dB gain
• Charging Case, LED Indicators

Godox WEC-2 Overview

Record 2-person vlogs or interviews with the Godox WEC 2-Person Wireless Microphone System using its two clip-on transmitters with built-in microphones and dual-channel receiver and 3.5mm TRS connector. Attach your transmitters to your talent’s lapel and mount your receiver to the cold shoe mount of your camera with the integrated belt clip. Use the included 3.5mm TRS and 3.5mm TRS to TRRS audio cables to connect the receiver to your camera or mobile device of choice. Both the receiver and transmitters can communicate from up to 200m away via 2.4 GHz frequency.
LED indicators on the components allow you to monitor power and mode status. Onboard controls toggle between mono and stereo modes, control the ±6 dB of gain, activate noise cancellation, or pair the devices to one another. Internal rechargeable batteries power the components for up to 8 hours at a time and can be recharged using the included charging case or USB-C ports.
Features at a Glance
• 2.4 GHz frequency, 200m transmission distance
• Dual-channel receiver with mono and stereo recording modes
• ±6 dB gain, intelligent noise reduction for improved vocals
• LED indicators and onboard controls
• 3.5mm TRS audio output port, USB-C charging ports
• 140mAh transmitter battery, 200mAh receiver battery, 8-hour battery life
• 1400mAh charging case extends runtime to 24 hours
• 3.5mm TRS cable, 3.5mm TRS to TRRS cable, furry windscreens, storage box

What’s In the Box:

• Godox WEC 2-Person Wireless Microphone System for Cameras and Mobile Devices (2.4 GHz)
• 2 x Godox WEC TX Clip-On Wireless Microphone Transmitter (2.4 GHz)
• Receiver
• Charging Case
• 2 x Furry Windscreen
• USB-A to USB-C Data Cable
• 3.5mm TRS Audio Cable
• 3.5mm TRS to TRRS Audio Cable
• Storage Case
• Limited 2 Year Godox SA Warranty

Godox WEC-2 Specs

System
Wireless Technology                                  Analog
Number of RF Channel Frequencies       2
Included Transmitters                   2x Clip-On with Microphone
Diversity                                           Non-Diversity
RF Channel Scanning                     Auto-Scan
Max Operating Range                     200 m
Max Transmitters per Band           2
Built-In Recorder                             No
Timecode Support                            No
Mobile App Compatible                  No
Sample Rate/Resolution                48 kHz / 16-Bit
Dynamic Range                                86 dB
Receiver
Receiver Type                                   Camera-Mount
Mounting Options                           Belt Clip (with Included Hardware)
Antenna                                             Internal
Number of Audio Channels           2
Audio I/O                                          1x 1/8″ / 3.5 mm TRS Unbalanced Output
Gain Range                                        -6 to +6 dB
Frequency Response                       20 Hz to 20 kHz
Network I/O                                     No
USB/Lightning Connectivity        USB-C Female (Charging)
USB Class-Compliant                     No, USB Charging/Power Only
Power Requirements                      Battery
Battery Type                                     1x Built-In Rechargeable
Internal Battery Capacity               200 mAh
Battery Charging Time                   2 Hours
Approx. Battery Life                        8 Hours
DC Input Power                                5 VDC at 200mA
Display & Indicators                        LED
Operating Temperature                   14 to 122°F / -10 to 50°C
Dimensions                                         48 x 28 x 15 mm
Weight                                                  16 g
Transmitter
Transmitter Type                              Clip-On with Microphone
RF Output Power                              Not Specified
Audio I/O                                             No
Auto-Level Control                             Yes
Gain Range                                          -6 +6 dB
Frequency Response                           20 Hz to 20 kHz
Sync Method                                         2.4 GHz QPSK
Antenna                                                 Internal
Power Requirements                           Battery
Battery Type                                          1x Built-In Rechargeable
Internal Battery Capacity                    140 mAh
Battery Charging Time                         2 Hours
Approx. Battery Life                              8 Hours
USB/Lightning                                        I/O USB-C (Charging)
Display & Indicators                              LED
Operating Temperature                         14 to 122°F / -10 to 50°C
Dimensions                                               48 x 22 x 16 mm
Weight                                                        12 g
Microphone
Microphone Type                                     Built-In (Transmitter)
Sound Field                                                Mono
Polar Pattern                                              Omnidirectional
Frequency Range                                       20 Hz to 20 kHz
Maximum SPL                                           110 dB SPL
Dynamic Range                                          86 dB
Operating Temperature                           14 to 122°F / -10 to 50°C
Charging Case
Additional Runtime with Charging Case      24 Hours
Recharge Time                                                   2 Hours
Battery Chemistry                                             Lithium-Ion
Capacity                                                              1400 mAh
Charging Interface                                           USB-C
DC Input Power                                               5 VDC at 1.3 A
Dimensions                                                      85 x 63 x 30 mm
Weight                                                              84 g
